100, 000pieces/Month
Wooden Box and Pallet or According to Your Demand
T/T
HCH
Regenerative Heat Exchanger
Ceramic
Heater
Plate Heat Exchanger
DXY
China
150*150*100mm, 100*100*150mm etc
25/40/43/50/60holes
Round, Square, Hexagonal, Triangular
Cordierite/Corundum Mullte/Mullite/Silicon Oxide
Rto
1320-1700
Product Description
Composition | Value(%) |
SiO2 | 25-29 |
Al2O3 | 62-67 |
MgO | 2-4 |
Fe2O3 | <1.2 |
TiO2 | <3.0 |
K2O+Na2O +CaO | <2.5 |
Size | Channels | Wall thickness (OD)(mm) | Wall thickness (ID)(mm) | Channel width (mm) | Surface area (m2/m3) | Void section (%) | Bulk density (kg/ m3) | Weight per pcs (kg) |
150×150×300 | 10×10 | 2.7 | 2.1 | 12.4 | 240 | 64 | 496 | 3.35 |
150×150×300 | 13×13 | 2.0 | 1.7 | 9.84 | 327 | 68.9 | 592 | 4.0 |
150×150×300 | 25×25 | 1.2 | 1.0 | 4.94 | 574 | 68 | 666 | 4.5 |
150×150×300 | 32×32 | 1.1 | 0.8 | 3.66 | 695 | 61 | 651 | 4.4 |
150×150×300 | 40×40 | 0.9 | 0.7 | 3.02 | 884 | 65 | 725 | 4.9 |
150×150×300 | 43×43 | 0.9 | 0.7 | 2.76 | 932 | 63 | 740 | 5.0 |
150×150×300 | 50×50 | 0.8 | 0.6 | 2.38 | 1082 | 63 | 770 | 5.2 |
150×150×300 | 60×60 | 0.7 | 0.5 | 1.99 | 1298 | 63 | 784 | 5.3 |
100×100×150 | 26×26 | 0.9 | 0.7 | 3.10 | 875 | 65 | 799 | 1.2 |
100×100×150 | 33×33 | 0.8 | 0.6 | 2.40 | 1083 | 63 | 866 | 1.3 |
