Shanghai, China
100, 000pieces/Month
L/C, T/T, D/P, Western Union, Paypal
CFA
12-25mm
Alumina Casting
DXY
Export Package: Wooden Box+Pallet
Diameter=30~500mm H=5~20mm
China
842199900
1200 Celsius Degree
Long Time Materials
Refractory Material
Rectangle, Round, Square
Alumina
10ppi, 20ppi, 30ppi, 40ppi, 50ppi, 60ppi
Product Description
| Chemical composition | Al 2 O 3 | Fe 2 O 3 | SiO 2 | others |
| model index(%) | 89.6 | 0.24 | 2.42 | 7.5 |
| item | density(g.cm 3 ) | Rupture modulus(816 ° C Mpa) | Compressive strength(Mpa) | Max operating temperature( ° C) |
| model index | 0.52 | 4.8 | 0.51 | 1280 |
| No. | Size (mm) | Flow velocity (Kg/s) | Filter capacity (Kg) | ||
| Gray castiron | Ductile castiron | Gray castiron | Ductile castiron | ||
| 1 | 30 × 50 × 22 | 2~4 | 1~3 | 45~60 | 15~30 |
| 2 | 40 × 40 × 11 | 2~4 | 1~3 | 45~60 | 15~30 |
| 40 × 40 × 13 | 2~4 | 1~3 | 45~60 | 15~30 | |
| 40 × 40 × 22 | 2~4 | 1~3 | 45~60 | 15~30 | |
| 3 | 50 × 50 × 13 | 3~6 | 2~4 | 55~90 | 25~45 |
| 50 × 50 × 22 | 3~6 | 2~4 | 55~90 | 25~45 | |
| 4 | 60 × 60 × 22 | 4~8 | 3~5 | 65~110 | 40~75 |
| 5 | 66 × 66 × 22 | 5~9 | 4~6 | 80~130 | 45~80 |
| 6 | 75 × 50 × 22 | 4~8 | 5~7 | 65~110 | 40~75 |
| 7 | 75 × 75 × 22 | 9~14 | 6~9 | 145~220 | 70~100 |
| 8 | Φ 50 × 22 | 3~5 | 1~3 | 50~70 | 20~40 |
| 9 | Φ 60 × 22 | 3~6 | 2~4 | 65~110 | 35~60 |
| 10 | Φ 70 × 22 | 4~8 | 3~6 | 75~130 | 40~75 |
| 11 | Φ 76 × 22 | 5~9 | 4~7 | 90~150 | 45~80 |
| 12 | Φ 90 × 22 | 10~15 | 6~9 | 180~260 | 75~110 |
| 13 | 100 × 50 × 22 | 8~12 | 5~8 | 130~200 | 65~90 |
| 14 | 100 × 60 × 22 | 9~14 | 6~9 | 180~260 | 70~100 |
| 15 | 150 × 100 × 22 | 18~25 | 12~16 | 300~ 400 | 150~210 |
| 16 | 150 × 150 × 22 | 35~50 | 24~36 | 400~ 900 | 300~450 |
