Alumina Ceramic Honeycomb Filter for Heat Storage
You are here: Home » Products » Foam Ceramic Filter » Al2O3 Ceramic Foam Filter » Alumina Ceramic Honeycomb Filter for Heat Storage

Alumina Ceramic Honeycomb Filter for Heat Storage

Quantity:
  • Shanghai, China
  • 100, 000pieces/Month
  • L/C, T/T, Western Union
  • CHF
  • Square, Circular, Triangular, Hexagonal, etc
  • 100cpsi, 200cpsi, 300cpsi, etc
  • Wooden Box, Carton Box with Pallet
  • China
  • 69039000
  • 1580< Refractoriness< 1770
  • Long Time Materials
  • Refractory Material
  • Square, Circular, Triangular, etc
  • Mullite, Cordierite, High Alumina, etc
  • 50*50, 40*40, 65*65, 50*75, etc

Product Description

Ceramic honeycomb filter for metal melting:
Honeycomb ceramic filter plate are widely used in metallurgy and casting industry for the filter of melted metal. Use mullite, cordierite, as its material and quality high density channel have endowed the products with good heat compression resistance and high casting temperature resistance, besides, flat channel design of honeycomb ceramic filter enable the balance between air flow rate and strength, and to remove the contaminants and cast particulates effectively, which hence improve the casting mechanic capability, surface look and product pass rate greatly.

Alumina Ceramic Honeycomb Filter for Heat Storage

Series of products of new material honeycomb ceramics takes the key part in environment protecting industry, which includes industrial waste gas, waste water purified, rubbish burning etc., at the same time, it is the first choice for the material of heat exchanger, regenerator, Gas stove etc., which relates to environment protecting product.

At melting metal liquid at ceramic hole eyes, in order to removing metal the refractory piece, alloy and melt the inclusion, such as dreg, etc. That melts of solution. The ceramic filter of honeycomb still plays a peculiar rectification role, can get steady and fast solution laminar flow, can prevent bubbles from entering, avoid the harmful effects that cause by the turbulance makes the metal oxidize and splash by the solution.

Size customized
Ceramic Honeycomb Filter is a fine strainer with straight hole structure, which provides a cost-efficient alternative to more effective ceramic foam filter.
We can produce different size of extruded ceramic filter; They have better handling properties than ceramic foam filters.

Advantages:
*Good work strength under high temperature, good thermal shock resistance and melted metal inflow resistance
*High strength under room temperature, mechanic push resistance
*Obvious filter effect
*Ease the uneven inflow of casting, smooth the casting process, avoid surface defect
*Have a large and even melted inflow rate
*Good chemical stability, not affected by of melted meta, no change in its chemical compound
*Precise dimension and can be used in production line automatic filter mounting equipment
Alumina Ceramic Honeycomb Filter for Heat Storage
Item
material
Al2O3
(%)
Hole type Milli hole( μ m) Coefficient of Thermal Expansion ( × 10-6/ ° C) Softening temperature
( ° C)
Max. Working temperature
( ° C)
Compressive Strength (MPa)
Cordierite 37 Round, square and delthyrium 2-3 ≤ 1.8 1390 1350 ≥ 12
Mullite 46 2-3 ≤ 4.0 1550 1500 ≥ 15
ZrO-Mullite 70 2-3 ≤ 5.5 1650 1580 ≥ 15
ZrO-Corundum 70 2-3 ≤ 5.5 1700 1650 ≥ 15
size(mm) Hole shape Aperture (mm) Hole quantity
(PCS)
Cell-opening
ratio (%)
Pieces per cube
100 × 100 × (20) Square 2.2 × 2.2 33 × 33=1089 52.70 (5000)
100 × 100 × (20) Square 2.5 × 2.5 31 × 31=961 60.06 (5000)
100 × 100 × (20) Square 3.0 × 3.0 24 × 24=576 51.84 (5000)
81 × 81 × (12.5) Square 1.46 × 1.46 44 × 44=1936 62.89 (12193)
75 × 75 × (15) Square 2.2 × 2.2 26 × 26=676 58.17 (11852)
75 × 75 × (15) Round Φ 2.5 492 42.94 (11852)
120 × 65 × (20) Square 2.2 × 2.2 38 × 20=760 47.16 (6410)
100 × 65 × (20) Square 2.2 × 2.2 33 × 21=693 51.6 (7692)
100 × 60 × (12.5) Square 2.2 × 2.2 33 × 20=660 53.29 (13333)
100 × 50 × (20) Square 1.6 × 1.6 50 × 24=1200 61.44 (10000)
66 × 66 × (12.5) Square 1.2 × 1.2 42 × 42=1764 58.31 (18365)
66 × 66 × (12.5) Square 1.46 × 1.46 37 × 37=1369 66.99 (18365)
66 × 66 × (12.5) Square 2.2 × 2.2 26 × 26=676 75.11 (18365)
66 × 66 × (12.5) Round Φ 2.4 440 45.7 (18365)
60 × 60 × (20) Square 1.6 × 1.6 29 × 29=841 59.80 (13889)
60 × 60 × (15) Square 2.2 × 2.2 20 × 20=400 53.78 (18519)
55 × 55 × (12.5) Round Φ 2.3 367 50.41 (26446)
55 × 55 × (12.5) Square 2.2 × 2.2 21 × 21=441 70.56 (26446)
55 × 55 × (12.5) Square 1.15 × 1.15 37 × 37=1369 59.85 (26446)
50 × 50 × (12) Square 2.2 × 2.2 19 × 19=361 69.89 (33333)
50 × 50 × (12.5) Round Φ 2.3 294 48.86 (32000)
40 × 40 × (10) Round Φ 2.2 172 40.86 (62500)
40 × 40 × (10) Square 1.4 × 1.4 22 × 22=484 59.29 (62500)
Φ 90 × (12.5) Square 2.2 × 2.2 696 52.95 (12582)
Φ 60 × (10) Square 1.44 × 1.44 502 36.82 (35368)
Φ 52 × (7) Square 2 × 2 234 44.07 (67304)
Φ 52 × (7) Square 1.44 × 1.44 286 27.93 (67304)
Φ 50 × (10) Round Φ 2.3 109 23.06 (50955)
