| Quantity: | |
|---|---|
Shanghai, China
100, 000pieces/Month
L/C, T/T, Western Union
DPF
100-600cpsi
as Catalyst Used in Diesel Engine
DXY
Wooden Box/Carton Box with Pallet
China
84213990
Ceramic
Euro IV
ISO9001, TS16949
Catalytic Converter
Sic
190*200mm, 286*305mm, 224*305mm etc
Product Description
| Component | Unit | Data | Component | Unit | Data |
| SiO2 | wt% | 48-51 | Fe2O3 | wt% | <0.5 |
| Al2O3 | wt% | 31-34 | Na2O | wt% | <0.5 |
| MgO | wt% | 14-16 | K2O | wt% | <0.5 |
| Property (uncatalyzed) | 100/17 | 200/12 | |
| Cell density | cpsi | 100 | 200 |
| cpscm | 15.5 | 31.0 | |
| Wall thickness | inch | 0.017 | 0.012 |
| mm | 0.432 | 0.305 | |
| Open frontal area (OFA), % | 34.5 | 34.5 | |
| Geometric surface area (GSA) | Inch2 | 33.3 | 47.0 |
| m2/l | 1.31 | 1.85 | |
| Hydraulic diameter | Inch | 0.083 | 0.059 |
| mm | 2.11 | 1.49 | |
| Modulus of rupture (psi/cpscm) | 350 | 300 | |
| Porosity (%) | 48 | 48 | |
| Coefficient of thermal expansion 102 cm/cm/ (20-800) --maximum average | 5 | 5 | |
| Mean pore size (micron) | 13 | 13 | |
| Melting temperature (Degree C) | 1460 | 1460 | |
| NO. | Item | Our products | |
| 1 | Filter material | Cordierite and Silicon carbide | |
| 2 | Operating temperature limit (Degree C) | 1000 | |
| 3 | Dimension (mm) | Ø144x150,Ø144x152.4,Ø150x150,Ø190x200,Ø190x203, Ø240x240,Ø240x305 Ø260x305, Ø267x305, Ø286x305, Ø286x355,Ø374x270x317 | |
| 4 | Cell pitch (mm) | 100 cpsi | |
| 5 | Cell wall thickness (mm) | 0.45-0.52 | |
| 6 | Cell size (mm) | 2.02-2.09 | |
| 7 | Mean pore size (um) | 8-13 | |
| 8 | Porosity (gas pocket rate) % | 50-55 | |
| 9 | Coefficient of thermal expansion | 1.6x10-6 | |
| 10 | Softening temperature (Degree C) | 1360 | |
| 11 | Compressive Strength (Mpa) | Lengthwise direction | 10 |
| Lateral direction | 2 | ||
| 12 | Water absorption rate: | 35% | |
