100, 000pieces/Month
Wooden Box/Carton Box with Pallet
L/C, T/T, Western Union
ICP
Heater
Plate
Ceramic Heater
Gas Scrubber
Immersive Snake Tube Heat Exchanger
Plate Heat Exchanger
DXY
China
132*92*13, 183*131*13.5, etc
Furnace, Pizza Furnace, BBQ
Regenerative Heat Exchanger
Ceramic
Aluminum Heat Exchanger
Ceramic Heating Equipment
Product Description
| Item | Unit | Value |
| Cell density | CPSI | 260-520 |
| Wall thickness | Cm | 0.18-0.28 |
| Open porosity | % | 63-73 |
| Capacity | g/L | 0.45-0.65 |
| Hot coefficient expansion | 10-6/k-1 | 2.0-2.5 |
| Heat capacity | J/kg | 0.85-1.0 |
| Thermal conductivity | W/MK | 1.5-2.5 |
| Max use temperature | Celsius Degree | 1375 |
| Compressive strength(vertical) | Mpa | ≥10 |
| Name | Unit | Value |
| SiO2 | % | 39-44 |
| Al2O3 | % | 47 -52 |
| MgO | % | 5-7 |
| Fe2O3 | % | ≤1 |
| TiO2 | % | ≤1.9 |
| K2O+Na2O+CaO | % | ≤2 |
| Material | Cordierite |
| Density of hole | 260 cpsi, 280cpsi, 320cpsi, 520 cpsi |
| Thickness of wall | 0.18-0.23mm / 0.28-0.33mm / 0.35-0.40mm |
| Size of sides | 1.06mm 1.13mm 1.2mm |
| Distance of two central holes | 1.33-1.59mm |
| Porosity | 63.5-73.5% |
| Water absorption | > 40% |
| Thermal expansion | 2.0-2.5×10-6 |
| Thermal stability | 1200celsius degree--25celsius degree,no crack |
| Strength compressive | vertical>10.0Mpatransverse>3.0Mpa |
