100, 000pieces/Month
Wooden Box and Pallet or Packaged as Your Request
L/C, T/T, Western Union
ICP
Ceramic
Ceramic Heating Equipment
Heater
Plate
Ceramic Heater
Plate Heat Exchanger
DXY
China
133*93*13mm, 250*145*15mm, etc
Round, Square, etc
Round, Cinquefoil, Diamond, etc
1.4mm, 1.6mm, 1.8mm, etc
Furnace, Pizza Furnace, BBQ, etc
Regenerative Heat Exchanger
Product Description
Chemical composition | Content | Chemical composition | Content |
Al 2 O 3 | 20-85 | Acid resistance % | ≥ 99.8% |
SiO 2 + Al 2 O 3 | 92 | Alkali resistance % | ≥ 86% |
Fe 2 O 3 | <0.8 | Refractoriness ° C | ≥ 1200 ° C |
Out porous ratio | 7.0-10% | Thermal stability | No crack after three times |
Specification mm | Fuel gas | hole | Cells/In 2 (CPSI) | suuface | ||||||
NG | LPG | square | round | square | round | plane | Convex diamond Pattern | Concave Cinquefoil pattern | Corrugatoin pattern | |
Φ 100 | √ | √ | √ | - | 280-520 | - | √ | √ | - | √ |
Φ 110 | √ | √ | √ | - | 280-520 | - | √ | √ | - | √ |
Φ 120 | √ | √ | √ | - | 280-520 | - | √ | √ | - | √ |
Φ 150 | √ | √ | √ | - | 280-520 | - | √ | √ | - | √ |
Φ 80 | √ | √ | √ | - | 280-520 | - | √ | √ | - | √ |
Φ 135 | √ | √ | √ | - | 280-520 | - | √ | √ | - | √ |
Φ 160 | √ | √ | √ | - | 280-520 | - | √ | √ | - | √ |
