Shanghai, China
100, 000pieces/Month
L/C, T/T, Western Union, Paypal
CHS
Cordierite
as Catalyst Used in Automobile/Motorcycle
Round, Square
DXY
Wooden Box/Carton Box with Pallet
China
6909190000
Ceramic
Euro IV
ISO9001
Catalytic Converter
White
100-600cpsi
Product Description
| No | Index | Unit | Value |
| 1 | Gross Density | g/cm3 | 2.3-2.6 |
| 2 | Average Linear Expansion(20-1000celsius degree) | 10-6/k-1 | 6-7.6 |
| 3 | Specific Heat Capacity | KJ/Kg | 900-1200 |
| 4 | Heat Conductivity | W/MK | 1.8-3 |
| 5 | Soft Temp. | celsius degree | 1400 |
| 6 | Maximum Application Temp. | celsius degree | 1350 |
| 7 | Corrosion Resistance Against Acid | celsius degree | 99.5 |
| Dimension | Quantity of channels | Wall thickness (mm) | Channel Width (mm) | Surface area (m2/m3) | Void section (%) | Packaging density (kg/ m3) | Weight per piece (kg) |
| 150×150×300 | 25×25 | 1.0 | 4.96 | 580 | 68 | 696 | 4.7 |
| 150×150×300 | 32×32 | 1.0 | 3.66 | 695 | 61 | 755 | 5.1 |
| 150×150×300 | 40×40 | 0.7 | 3.03 | 891 | 65 | 814 | 5.5 |
| 150×150×300 | 43×43 | 0.7 | 2.77 | 940 | 63 | 858 | 5.8 |
| 150×150×300 | 50×50 | 0.6 | 2.39 | 1090 | 63 | 903 | 6.1 |
