Honeycomb Ceramic Diesel Particulate Filter
You are here: Home » Products » Diesel Particulate Filter » Others Diesel Particulate Filter » Honeycomb Ceramic Diesel Particulate Filter

Honeycomb Ceramic Diesel Particulate Filter

Quantity:
sharethis sharing button
  • 100, 000m3/Month

  • Wooden Box/Carton Box with Pallet

  • L/C, T/T, D/P, Western Union, Paypal

  • DPF

  • The Brake Noise

  • Catalytic Converter

  • Europe

  • 286*305, 286*100, 144*152.4, 240*305 etc

  • 100-200cpsi

  • White/Green

  • as Catalyst Used in Diesel Engine

  • DXY

  • China

  • 842139900

  • Catalytic Converter

  • Aluminium

  • Euro IV

  • ISO9001, TS16949

  • The Noise of Engine

  • Mechanical Noise

Product Description

Diesel Particulate Filters
Diesel Particulate Filters relates high-pure Sic Honeycomb-shaped ceramic catacher. quality certificate pass ISO/TS16949. Quality control pass ISO/TS16949 and catalyst reach EURO5/EURO4/EURO3/EURO2/ CARB OBDII/ EPA. Diesel Particulate Filters has succesefully installed in cars, buses, trucks, and various construction machinery vehiles, DPF's life WITHIN the 300,000km, collection efficiency range 97percent. Heat regeneration is made through the displacement management, and the ashes left from the regeneration shall be cleaned regularly.

After coated with catalysts, this product is applied in catalytic converter of diesel vehicle to catalyze, convert and purify the exhaust, making vehicle exhaust reaching standards of Euro IV and Euro V. Technical performance of the product in the leading position in domestic, close to or reach the advanced level of similar foreign product.

Benefits of Products:
*Low thermal expansion coefficient
*High porosity of hole on the wall , good liquidity and uniform distribution.
*High temperature resistance, chemical corrosion resistance, thermal shock resistance and thermal shock resistance is strong.
*The pressure drop is small.
*Cold start performance is good, low light-off temperature, high conversion efficiency.
Honeycomb Ceramic Diesel Particulate Filter
Honeycomb Ceramic Diesel Particulate Filter
Honeycomb Ceramic Diesel Particulate Filter

NO. Item Diesel particulate filter
1 Filter material Cordierite and Silicon carbide
2 Operating temperature limit (Degree C) 1000
3 Dimension (mm) Ø144x150,Ø144x152.4,Ø150x150,Ø190x200,Ø190x203, Ø240x240,Ø240x305 Ø260x305, Ø267x305, Ø286x305, Ø286x355,Ø374x270x317
4 Cell pitch (mm) 100 cpsi
5 Cell wall thickness (mm) 0.45-0.52
6 Cell size (mm) 2.02-2.09
7 Mean pore size (um) 8-13
8 Porosity (gas pocket rate) % 50-55
9 Coefficient of thermal expansion 1.6x10-6
10 Softening temperature (Degree) 1360
11 Compressive Strength (Mpa) Lengthwise direction 10
Lateral direction 2
12 Water absorption rate: 35%
Property (uncatalyzed) 100/17 200/12
Cell density cpsi 100 200
cpscm 15.5 31.0
Wall thickness inch 0.017 0.012
mm 0.432 0.305
Open frontal area (OFA), % 34.5 34.5
Geometric surface area (GSA) Inch2 33.3 47.0
m2/l 1.31 1.85
Hydraulic diameter Inch 0.083 0.059
mm 2.11 1.49
Modulus of rupture (psi/cpscm) 350 300
Porosity (%) 48 48
Coefficient of thermal expansion
102 cm/cm/ (20-800) --maximum average
5 5
Mean pore size (micron) 13 13
Melting temperature (Degree C) 1460 1460
Component Unit Data Component Unit Data
SiO2 wt% 48-51 Fe2O3 wt% <0.5
Al2O3 wt% 31-34 Na2O wt% <0.5
MgO wt% 14-16 K2O wt% <0.5
