Shanghai, China
100, 000pieces/Month
L/C, T/T, Western Union, Paypal
ICP
Ceramic
Heater
Plate Heat Exchanger
DXY
Wooden Box and Pallet or Packaged as Your Request
China
6909190000
133*93*13mm, 250*145*15mm, etc
Round, Square, etc
Round, Cinquefoil, Diamond, etc
1.4mm, 1.6mm, 1.8mm, etc
Metallurgical Operation
Regenerative Heat Exchanger
Product Description
Hole | Round hole | Square hole |
Material | cordierite | cordierite |
Volume density | 0.45-0.65g/L | 0.45-0.65g/L |
Hole density | 300-320 hole/in 2 | 260 hole/in 2 ,280 hole/in 2 ,320 hole/in 2 ,520 hole/in 2 |
Wall thickness | / | 0.18-0.23mm,0.28-0.33mm, 0.35-0.40mm |
Length of side of hole | / | 1.06mm,1.13mm,1.2mm |
Hole diameter | 1.12mm,1.25mm,1.42mm | / |
Distance between Two Holes Axis | 1.8mm,2.2mm,2.7mm | 1.33-1.59mm |
Open hole ratio | 33.5-46.5% | 63.5-73.5% |
Water-absorbing rate(%) | > 46% | > 40% |
thermal expansion coefficient | 2.0-2.3 × 10 -6 | 2.0-2.5 × 10 -6 |
Heat stability | 850 ° C--25 ° C, do not crack in three times | 1200 ° C--25 ° C, do not crack in the condition of reduplicate cooling |
Highest Working Temperature( ° C) | > 1375 ° C | > 1375 ° C |
Compression Strength (Lengthways) | >13.0Mpa | >10.0Mpa |
Compression Strength (Horizontal) | >6.0Mpa | >3.0Mpa |
Rotundity shape | Ellipse shape | ||
Specificationmm | Number of channels (holes /square inch) | Specification (mm) | Number of channels (holes /square inch) |
Φ 83 × 85 | 400 | T146.8 × 77 × 86.4 | 400 |
Φ 144 × 152.4 | 400 | T120.6 × 80 × 152.4 | 400 |
Φ 100 × 100 | 400 | T169.7 × 80.7 × 76.2 | 400 |
Φ 130 × 130 | 400 | T144.8 × 81.3 × 152.4 | 400 |
Φ 118 × 150 | 400 | T144.8 × 81 × 76.2 | 400 |
Φ 103 × 100 | 400 | T169.7 × 80.7 × 101.6 | 400 |
Φ 150 × 75 | 400 | T144.8 × 81.3 × 100 | 300 |
Φ 83 × 125 | 400 | T127 × 63.5 × 107 | 300 |
Φ 150 × 150 | 300 | T144.8 × 81.3 × 70 | 300 |
Φ 120 × 100 | 300 | T144.8 × 81.3 × 150 | 300 |
Φ 101.6 × 100 | 300 | Race track shape | |
Φ 94 × 100 | 300 | P120.65 × 80.01 × 76.2 | 400 |
Φ 85 × 70 | 300 | P120.65 × 80.01 × 76.2 | 200 |
Φ 93 × 76 | 200 | P144 × 68 × 150 | 400 |
Φ 118 × 76 | 200 | P125 × 80 × 100 | 400 |
