Motorcycle Metal Honeycomb Substrate Catalytic Converter
You are here: Home » Products » Honeycomb Metal Substrate » Motorcycle Metal Honeycomb Substrate Catalytic Converter

Motorcycle Metal Honeycomb Substrate Catalytic Converter

sharethis sharing button
  • Shanghai, China

  • 100, 000pieces/Month

  • L/C, T/T, Western Union

  • MHS

  • The Brake Noise

  • Catalytic Converter

  • Europe

  • SS304, SS316

  • as Catalyst Used in Automobile/Motorcycle

  • 100-600cpsi

  • 0.04-0.1

  • 10-250

  • 1100°c

  • 1250°c

  • DXY

  • Wooden Box and Pallet/Packed as Customers′ Need

  • all size

  • China

  • 84213990

  • Catalytic Converter

  • Steel

  • Euro V

  • ISO9001, TS16949

  • The Noise of Engine

  • Mechanical Noise

Product Description

Metal Honeycomb Substrate With Top Quality And Attractive Price:

Passing through the strict test of endurance, our motorcycle catalyst converter has met European emission standard, and the economical sloss (loss) of motorcycle's power could be less than 3%. Its catalyst carrier includes: Metallic catalyst carrier and honeycomb ceramic catalyst carrier. We could customize the products according to clients's different requirement. To make the product with tri-angle, round and square hole as well as other specification in accordance with customer's demand. High temperature resistant and excellent catalyst activated technique which can make the engine can keep well exhaust function in the working environment. It can be specialized designed for the customers various vehicle type, hence can achieve ideal engine function and match the exhaust emission standard.

Metallic substrate is with the advantages of fast burning, small volume, high mechanical strength, prominent heat-resistance, etc. It is widely used in exhaust gas purification, especially for motorbike. High strength complex substrate plus big surface area and active element of noble metal could lower down pollutant value of motorcycle exhaust efficiently, such as CO, HC, NOX etc...Our catalyst type: Complex catalyst of noble metal (Pt, Pd, Rh) plus rare earth complex catalyst.
B. Catalytic substrate: Metal substrate and honeycomb ceramic substrate. Fantastic coating fastness and stably and long-term catalyst ability. Advanced technic of substrates making and canning, ensuring depandable resistance heat shocks and stability of equipment. Various kinds of specifications and types, customized products as per clients specific requirement and technology data.

*Round & Ovel metallic substrate for On-road vehicle
*Metallic substrate for small engine
*Metallic substrate for Off-road vehicle
*Metallic substrate for industrial catalyst
*Specific structure metallic substrate for other application

High dispersion of precious metal:
*Low light -off temperature
*Excellent oxygen storage ability wide span of λ
*Good performance against high temperature
*Ruduces emission of CO, HC, NOx by up to 98%
*Can be provided in a standard or custom configuration
*Excellent and stable double-coating technology
*Excellent resistance to sulfur poisoning properties
*Meet the Standards European II ~ Europe V emission standard approved Motorcycle Metal Honeycomb Substrate Catalytic Converter
Shape Material Diameter Length Channel density(cpsi)
Cylinder Fe/Cr/Al 35 40/60/70/100 100/200
Cylinder Fe/Cr/Al 38 100 100/200
Cylinder Fe/Cr/Al 42 100 100/200
Cylinder Fe/Cr/Al 48.6 70/100/130 100/200/300
Cylinder Fe/Cr/Al 63 50/75/100/130 200/300/400
Cylinder Fe/Cr/Al 73 70/100/130 200/300/400
Cylinder Fe/Cr/Al 93 100/130 200/300/400
Cylinder Fe/Cr/Al 101.6 100/130 200/300/400
Cylinder Fe/Cr/Al 420 100/130 300/400

Mantle Matrix Brazing
Ferritel (SUS444, SUS441, SUS430) Fe-Cr-Al with RE, Zr/Ti additions high temperature oxidation resistant special alloy
Domestic FeCrAl(2073/216)
Import FeCrAl(1.4725/1.4767)
Nickel base alloy
or Austenitic heat resistant stainless steel (SUS304)
