Cordierite Ceramic Honeycomb Substrate Honeycomb Ceramic Catalyst for Vehicle
You are here: Home » Products » Honeycomb Catalyst Substrate » Ceramic Honeycomb Substrate » Cordierite Ceramic Honeycomb Substrate Honeycomb Ceramic Catalyst for Vehicle

Cordierite Ceramic Honeycomb Substrate Honeycomb Ceramic Catalyst for Vehicle

Quantity:
  • Shanghai, China
  • 100, 000pieces/Month
  • L/C, T/T, Western Union, Paypal
  • CHS
  • The Brake Noise
  • Catalytic Converter
  • South America
  • Cordierite
  • Round, Oval or Race Track
  • as Catalyst Used in Automobile/Motorcycle
  • 200-600cpsi
  • DXY
  • Wooden Box and Pallet/Packed as Customers′ Need
  • China
  • 6909190000
  • Catalytic Converter
  • Ceramic
  • Euroii-Eurov
  • ISO9001, TS16949
  • Mechanical Noise and Combustion
  • Mechanical Noise

Product Description

We can offer various alternatives to provide customers with substrates and catalysts to meet demanding requirements. Honeycomb ceramic substrates are available for gasoline powered vehicles in 6 standard cell densities: 100, 200, 300, 400, 500, and 600 cells per square inch. Shape: Round, Oval or Race Track.

Cordierite Ceramic Honeycomb Substrate Honeycomb Ceramic Catalyst for Vehicle

*Materials
Mullite, Cordierite ceramics and zircon chrome corundum, etc.

*Application
1) As support of catalyst, ceramic honeycomb materials are typically used for purifying automotive emission, removing bad smell etc.
2) As heat exchange media, ceramic honeycomb materials are mainly utilized in heat recovery unit of RTO's instead of ceramic saddles.
3) As filtrate substrate, ceramic honeycomb materials are generally utilized in food processing, water treatment, environmental industry, metallurgical industry etc.

*Shapes and sizes
1) The shapes include as follows: Round, square, triangular, sector, or to be customized etc.
2) The size include below: Standard type 150mm x 150mm x 300mm, 100mm x 100mm x 100mm, 100mm x 100mm x 150mm, other size can be manufactured according to customers' requirements.

*Types
Ceramic Honeycomb Catalytic Converter
Infrared Honeycomb Ceramic Plate
Ceramic Honeycomb Filter
Heat Transfer Media for RTO
Catalyst Support Monolith
Honeycomb Ceramic

Cordierite Ceramic Honeycomb Substrate Honeycomb Ceramic Catalyst for Vehicle

*Advantages
Catalyst carrier: It can clean waste gas.
Heat transfer agent: It can save 12% of energy in heat exchange.
Refractory stove: Low mass/volume, fast heat conduction.
Gas burn distributing plate: Complete burn, energy saving is 10%.
Items Parameters
Cordierite crystal phase ≥90%
Coefficient of Thermal Expansion(20-800Degree C) ≤1.2×10-6/Degree C
Thermal Stability(20-650Degree C) 3 times
Soften Temperature ≥1400 Degree C
Water Absorption 23-25%
Bulk Density 0.40-0.50Kg/L
Tolerance of outside dimensions ±1%
Compression Strength Lengthways ≥15MPa
Horizontal ≥3MPa
Wall thickness 100 CPSI 0.43 mm
200 CPSI 0.32 mm
300 CPSI 0.30 mm
400 CPSI 0.18 mm
600 CPSI 0.15 mm
Size (mm) Size (mm) Size (mm) Size (mm)
ø76.2x50 ø93x85 ø103.0x130 ø118.4x118.4
ø76.2x101.6 ø93x88.3 ø105.7x130 ø118.4x120
ø80x50 ø93x100 ø105.7x147.5 ø118.4x127
ø80x60 ø93x110 ø105.7x152.4 ø118.4x140
ø80x95 ø93x101.6 ø106.1x152.4 ø118.4x152.4
ø83x60 ø93x118 ø107.1x80 ø132.1x100
ø83x80 ø93x130 ø107.1x130 ø143.76x127
ø83x85 ø93x152.4 ø107.1x100.4 ø143.8x75
ø83x100 ø93x170 ø110x80 ø143.8x152.4
ø83x115 ø97x88.9 ø110x130 ø143.8x177.8
ø83x125 ø97x114.3 ø110x165 ø150x66
ø87x60 ø97x170 ø118.4x50.8 ø150x100
ø88x85 ø101.6x50 ø118.4x55 ø150x150
ø88x170 ø101.6x76.2 ø118.4x60 ø170x50
ø92x90 ø101.6x90 ø118.4x75 ø170x70
ø93x60 ø101.6x100 ø118.4x95 ø170x100
ø93x75 ø101.6x123.3 ø118.4x100 ø180x60
ø93x76 ø101.6x152.4 ø118.4x114.3 ø180x270
Size (mm) Size (mm) Size (mm) Size (mm)
57x80x76(Oval) 120.65x80.01x100 144x84x130 147x95x152.4
57x80x85(Oval) 120.65x80.01x120 144.3x68.1x45 148x84x50
95x115x132 120.65x80.01x125 144.3x68.1x125 148x84x76
99.5x68x120 120.65x80.01x140 144.3x68.1x152.4 148x84x80
112x60x80 120.65x80.01x152.4 144.8x81.3x76 148x84x96
112/80x90x152.4 125x80x101.6 144.8x81.3x152.4 148x84x115
114x105x105 125x80x152.4 147x95x45 148x84x125
120.65x80.01x45 127x63.5x107 147x95x50 148x84x140
120.65x80.01x50 143.5x84x155 147x95x120 148x84x152.4
120.65x80.01x75 144x68x125 147x95x140
